LHR12E

All-in-one sanding and polishing system for painted surfaces
Duetto is equally effective working with soft or interface backing pads teamed with micro-abrasives during the defect correction step or with foam polishing pads and compounds during the polishing stage. Extensive research on random orbital dynamics and exhaustive testing resulted in the choice of a 12mm orbit for Duetto. This orbit length greatly improves the surface rectification abilities of the latest generation of microabrasive discs. The combination of duetto and microabrasives is especially effective when smoothing orange peel or significant defects. The finish generated by this combination is both homogeneous and predictable, with no deep sanding marks.

The use of microabrasive discs to correct severe defects creates a surface that is easily polished, radically reducing the overall time of the full correction process. Duetto is so well balanced and low in vibration that the operator can easily control the sanding step by simply guiding duetto over the surface. The ability of the operator to control the tool so efficiently minimizes the chances of creating rough and uneven surfaces that require time-consuming rework.
Duetto has several design features that make it uniquely operator friendly.
The anti-spinning device reduces the chances of operator error even for a novice technician. The front hand grip allows the operator to place his/her hand at the virtual balance center of the tool and keeps vibration to a minimum.
The electronic module has built-in torque control, reducing the need for the operator to apply significant downward vertical pressure. Another unique duetto feature is the rubber support that allows the operator to place duetto on a workbench without the abrasive disc touching a surface that might contain contaminants that could transfer to the workpiece during the sanding process. Compatible with microabrasive discs and the appropriate 5” interface pad.

Available kits

LHR12E/STD

Random orbital polisher (Ø125mm - Ø5”-12mm orbit)(LHR12E)

LHR12E/STN

Random orbital polisher (Ø125mm - Ø5”-12mm orbit)(LHR12E)
ZEPHIR polishing compound 250ml COARSE(9.BFZEPHIR250)
KERAMIK polishing compound 250ml FINE(9.BFKERAMIK250)
Foam polishing pad COARSE Ø130-150mm - Ø5”- 6”(9.BF150H)
Foam polishing pad FINE Ø130-150mm - Ø5”- 6”(9.BF150M)
Soft interface(980.041)
3x Abrasives X-Cut P 2000(9.45401)
3x Abrasives X-Cut P 3000(9.45403)
4x Microfiber cloths(9.BF9010/4)

LHR12E/DLX

Random orbital polisher (Ø125mm - Ø5”-12mm orbit)(LHR12E)
BigFoot tools bag(9.Z883/BF)
ZEPHIR polishing compound 250ml COARSE(9.BFZEPHIR250)
KERAMIK polishing compound 250ml FINE(9.BFKERAMIK250 )
2x Foam polishing pads COARSE Ø130-150mm - Ø5”- 6”( 9.BF150H)
2x Foam polishing pads FINE Ø130-150mm - Ø5”- 6”(9.BF150M)
Soft interface(980.041)
3x Abrasives X-Cut P 2000(9.45401)
3x Abrasives X-Cut P 3000(9.45403)
4x Microfiber cloths(9.BF9010/4)
BigFoot apron(9.Z868)

LHR12E/BOX

Random orbital polisher (Ø125mm - Ø5”-12mm orbit)(LHR12E)
Systainer Case(9.CASEIII)
ZEPHIR polishing compound 250ml COARSE(9.BFZEPHIR250)
UNO PROTECT polishing compound 250ml(9.PROTECT250)
2x Wool Polishing Pad COARSE Ø130-145mm - Ø5”- 5,75”(9.BW150H)
2x Wool Polishing Pad FINE Ø130-145mm - Ø5”- 5,75”(9.BW150M)
BIGFOOT Claw pad tool(9.BF7001)
3x Abrasives X-Cut P 2000 Ø125mm(9.45401)
3x Abrasives X-Cut P 3000 Ø125mm(9.45403)
4x Microfiber cloths(9.BF9010/4)

Technical data

Backing pad thread  M8
Speed control  √
Weight   Kg  2,6
R.P.M.  4000-5500
Power  W/hp  400
Ø orbit   mm  12
Ø backing pad   mm  125
